Physiotherapy Exerciser

Advance Quadriceps Exerciser chair with back rest with double liver

TECHNICAL SPECIFICATIONS

• The Quadriceps chair & Backrest for all made of heavy duty Mild  steel square pipe with Powder coated finish.
• Torque Units made by crc pipe with chrome plated finish
• Torque Units: ONE set, (for Left OR Right Leg). Resistance Arms is calibrated so that resistance can be varied from Minimum, 1/2, 3/4 & Maximum without adding weights, the unit consists two lever arms, one of which hold contact for more information 9891242824 the Weights while the other arm with shin foam roller provides contact with the patient's leg.
•  Goniometry: A degree scale is provided on the torque unit to measure and record the range of motion from either Direction.
• Seat & Armrests: Fixed height, 2”hard density foam Seat with pu synthetic Leather is fitted with adjustable Arm-rests.
• Backrest: Foam padded back can be positioned from vertically to horizontally for more exercise options.
• Stabilizing Straps: Provided with torso & thigh straps for patient safety.
• Weight Plates provided :5 no .each plate weight 1 kg

Technical Specification

•  Arm Exerciser that allows effective weight resistive exercises at different levels for Shoulder, Elbow and Chest.
• Made by Chrome-plated, tubular steel construction mounted on wooden platform and fitted with painted wall-bracket at the top for wall mounting.
• Weight plates: One Set, (10 X 1kg plates in set)
• Handles: Two, (One for single grip & One for both hands).
• Pulley Block; Swivel pulley-block with Height Adjustment at different Levels.
• Rope Adjuster; Rope length can be adjusted as per Height level of Pulley Block.
• Ankle strap: One.
• Wall Mounting; Unit comes with wall fixing hard-ware

TECHNICAL SPECIFICATIONS

• 24" Inch Handle Rod for Smooth Shoulder Rotation, & 6” u shape handle wrist rotation  for Light weight, easy to install
• Resistance is controllable from zero to maximum by tightening the strap
• Adjust bar are chrome plated .comes with wall fixing electrode
• A 360 degree scale is provided on the drum to measure & record the degree of revolution from either direction (for Left or Right Shoulder) for immediate feed-back to the patient.

TECHNICAL SPECIFICATIONS

• Made of heavy duty Mild steel square pipe with Powder coated finish. Supply stability on any surface, this exerciser
• Pedals that resemble a bicycle feature integrated straps, keeping your feet securely in place
• The resistance can be adjusted with a tension screw, allowing you to increase or decrease the strength of your therapy to meet your personal ability level.
• To protect surfaces from scratches and scuff contact for more information 9891242824 marks, the base sports four anti-slip rubber pads
• A 5-function LCD readout displays your exercise time, revolution count, rpm and calories burned so you can keep track of your progress
• It can also be folded down for easy transport and storage.

TECHNICAL SPECIFICATIONS

• Made from eucalyptus wood and painted with Anti-humidity sealer.
• Hard - wood table with laminated top high.
• Fitted with 6 pulleys in a steel frame. Leather loops and nylon cord passing through the pulleys with hanging weight underneath for Fingers Hand, Wrist and Forearm exercises.
• Especially for Metatarsophalangeal & interphalangeal joints.
• Provided with Supinator/ Pronator and Wrist - Circumduction wheel for Wrist exercises.
• Comes with Five sets of weights, each set consists of 5 weights of One each of 100, 200, 300, 400 and 500 grams

 TECHNICAL SPECIFICATIONS

• The multi exerciser chair & Backrest for all made of heavy duty Mild steel square pipe with Powder coated finish.
• Overhead bar & weight carrier guide bars made by crc pipe with chrome plated finish
• Seat & Armrests: Fixed height, 2”hard density foam Seat with pu synthetic Leather is fitted with adjustable Arm-rests.
• Backrest: Foam padded back can be positioned from vertically to horizontally for more exercise options.
• Two sets, pulley blocks can be adjusted on overhead bar vertically. Pulley arms can be rotated (360 degrees) to adjust width.
• Stabilizing Straps: Provided with torso & thigh straps for patient safety.
• Size: Floor area, 100cm long x 67cm wide, the overhead bar extends 80cm beyond front portion of the frame.
• Accessories: Pulleys with rope: 2 set. Pulley block: 1 No. Wire handles: 2 No. Arm slings: 2 No. Ankle Straps: 2No. Gripping bar: 1No. Snap hooks : 4No , Weight Plates provided :10 no .each plate weight 1 kg

Technical Specification

• Physio care devices Made by Laminate ply wood  platform includes tapered ends and an anti-slip matting
• All Manual-Adjusting Parallel Bars heavy-gauge iron tubing, bars are mounted on strong metal frame power coting & platform with inclination on both ends & covered with non-slip matting.
• The handrails is single piece, circular in design stainless steel ribbed pipe of diameter is 1.5 inch Both the end of the handrails is fitted with steel cover.
• Physio care devices  Construction: Height & Width adjusting Arms are made of Chrome-Plated steel tubing of 38mm dia. Outer uprights of thick steel tubing (50mm dia) with Powder coating finish.
• Abduction Board: Detachable Abduction Board in two parts, which fits in the holes in the middle of the platform.
• Length: 304 cm ( 10 feet) with Hand-Rails made SS 304 grade tubing.
• Height: Adjustable from 55cm to 80cm.
• Width: Adjustable from 35 cm to 55cm.

TECHNICAL SPECIFICATIONS

• All 16g  mild still round pipe constructed with power coating
• 37.5” dia  wheel fitted with C.I drum
• Wheel is mounted on Three laminated hard-wood wall boards of which Two board are fitted with Two stainless steel channels (81cm H x 6cm W) to give contact for more information 9891242824 wheel 50cm height adjustment to suit each patient.
• Arc of motion can be varied from 30cm to 80cm by fixing handle at the required place
• Wheel is fitted with advanced Calibrated Sensitive Resistance mechanism and the resistance is controllable from Zero to Maximum.
• A 360 degree scale is provided on the drum to measure & record the degree of revolution from either direction (for Left or Right Shoulder) for immediate feed-back to the patient.

Specification

• Stair Made by best quality 18 mm ply board & painted Natural wood-polish finish covered with non-slip matting.
• Handrails made by Solid wood constructed frame work and painted Natural wood-polish finish
• The steps have 4 x 24cm high risers on one side and 6 x 15cm high risers on the other side. on one side leading to a platform of 60cm x 60cm
• Steps are 60cm wide & 23cm deep.
• Fitted with Two sets of handrails at different height to accommodate Adult and Children
• The stairs are built to convert from a straight line or 90-degree corner configuration
